Technical data 3
TW9 27
3.7 Axles
Front axle Rigidly-mounted planetary drive with integrated center-mounted
disc brake.
Self-locking differential (45%) as standard.
Rear axle (standard) Oscillating planetary drive axle with self-locking differential and
integrated reduction gear.
Rear axle (high-speed version) Oscillating planetary drive axle with self-locking differential and
integrated 2-stage reduction gear.
Angle of oscillation ± 10°
3.8 Tires
Tire size Tire pressures
front
Tire pressures
rear
12.5-18 MPT 2.8 1.8
12.5-20 MPT 2.5 1.8
14.5-20 MPT 2.0 1.5
335/80 R20 XM 2.5 1.7
335/80 R20 EM 2.5 2.5
405/70 R18 3.0 2.5
Special tires available on request!
If solid-rubber or foamed tires are used, special measures must be taken and restrictions apply.
The tire pressure refers to standard equipment.
During fork lift operations, the tire pressure of the front wheels must be increased by at least
0.5 bar.
