3 Technical data
32 TW9
3.12 Dimensions and weights
Specifications refer to general-purpose bucket and 405/70 R18 tires
Parallel
kinematics
Z
kinematics
Operating weight with standard equipment according to ISO
6016
kg 4,900 4,900
Total length, standard bucket on ground mm 5,060 5,085
Total width mm 1,850 1,850
Total height (cab roof) mm 2,640 2,640
Unladen weight mm 4,800 4,800
Wheel base mm 2,100 2,100
Track width FR / RR mm 1,390 1,390
Rear overhang angle ° 35 35
Ground clearance below propeller shaft mm 435 435
Turning radius at outside edge of bucket in transport position mm 4,160 4,160
Turning radius at outside edge of tires mm 3,780 3,780
Turning radius at inside edge of tires mm 1,980 1,980
3.13 Front loader installation
Specifications refer to general-purpose bucket and 405/70 R18 tires
Parallel
kinematics
Z kinematic
Width of bucket mm 1,850 1,850
Capacity in accordance with ISO 7546 (max. density = 1.8 t/m ³) approx. m³ 0.8 0.8
Payload in bucket 0.8 m³ x 1.8 t/m
³
or 0.9 m³ x 1.6 t/m
³
kg 1,440 1,440
Dump height at 45° dump angle approx. mm 2,550 2,550
Dump reach at max. dump height approx. mm 700 710
Max. bucket hinge pin height approx. mm 3,200 3,220
Reset angle ° 50 50
Dump angle at max. dump height ° 45 45
Digging depth, horizontal bucket approx. mm 100 110
Lift capacity at ground level according to ISO 14397-2 N 48,000 48,400
Ripping force at cutting edge of bucket according to ISO 14397-2 N 45,900 47,300
Tipping load, straight according to ISO 14397-1 kg 3,720 3,720
Tipping load, articulated according to ISO 14397-1 kg 3,280 3,280
Work cycle times, "Lift" sec. 4.7 4.9
Work cycle times “Lower” sec. 3.2 3.4
Dumping in uppermost position "In" sec. 1.1 1.1
Dumping in uppermost position, "Out" sec. 1.3 0.8
Stability conforms to ISO 14397-1
