Maintenance and Care 7
TW9 91
7.9.13 Axles
General
The axle oil must be changed at operating
temperature.
Collect the waste oil, do not allow it to
seep into the ground.
Dispose of according to regulations!
After filling the axles with oil, move the
machine for approx. 5 minutes to ensure
that the oil is evenly distributed.
Check the oil level again and top up if
necessary.
7.9.13.1 Front axle differential
Checking the axle oil level
• Remove the inspection plug (55/1) check and
top up oil if required.
Changing axle oil
• Park the machine on level ground.
• Open the inspection-filling plug (55/1).
• Open the drain plug (55/2) on the differential
and drain oil.
• Flush out the axle if necessary.
• Screw back on the drain plug carefully.
• Pour in oil using the inspection-filling hole until
oil escapes.
• Carefully close the inspection-filling plug.
Fig. 55 Front axle
