Operation 4
TW9 41
Description of fig. 10.2 - Instrument panel
20 Not assigned
21 ORANGE - pre-heating monitor
22 RED - battery charge indicator
23 RED - parking brake
24 GREEN - travel direction, forward
25 Coolant temperature
26 Operating hour meter
27 Fuel-level indicator
28 GREEN - travel direction, reverse
29 GREEN - direction indicator
30 BLUE - high beam
31 RED - engine oil pressure
32 RED - air filter indicator
33 Travel speed - FAST - SLOW
34 High-gear changeover switch
Only press if machine is at
standstill!
35 Multi-function switch with lock for
"working equipment" cut-off and
change-over of the "travel direction
preselection switches" from pos. 8 to
pos. 36
Only press if machine is at
standstill!
36 Preselection of travel direction -
Function only active if working
hydraulics are disabled
37 Not assigned*
38 Not assigned*
39 Not assigned*
40 Windshield washer function front/rear
41 Windshield wiper, front
42 Windshield wiper, rear
43 --
44 Fan switch - heating
45 Switch - air-conditioning
46 Not assigned*
47 Preselection button for actuation – 3rd
control circuit
48 Preselection button – float position
continuous operation
49 Not assigned*
50 Glow plug and starter switch
51 Hazard warning switch
52 Working floodlight front - switch on the
parking light (fig. 10.1, pos. 1)
53 Working floodlight rear - switch on the
parking light (fig. 10.1, pos. 1)
54 Not assigned*
55 Not assigned*
56 Potentiometer "flow rate" - 3rd control
circuit
57 Control - heating/air-conditioning
58 Monitor - indicator "manual
transmission range I"
59 Monitor - indicator "manual
transmission range II"
60 Monitor - indicator "manual
transmission not ready for operation"
If this symbol comes up, the
manual transmission is in an
intermediate position. The
machine is not ready for
driving! This can be remedied
by performing brief steering
movements until the manual
transmission engages.
61 Speed indicator
* for non-standard equipment
