Tally Dascom 5130P - Self-Diagnostics and Failure Indications

T
ally Dascom 5130P
24
USER2 Online Mode
Single sheet path selected:
- If paper is loaded from the front, pressing and releasing this key will feed paper
one line forward. If key is pressed down for more than 1 sec, printer will eject
the paper. Paper eject direction depends on configuration setting.
- If paper is loaded from the Tractors, pressing this key will not have any effect.
- If paper is not loaded, pressing this key will not have any effect.
Tractors path selected:
- When paper is loaded from the Tractors, pressing and releasing this key will
feed paper one line forward. If key is pressed down for more than 1 sec, the
printer will perform a form feed.
- When paper is not loaded, pressing this key will not have any effect.
Offline Mode
Single sheet path selected:
- Pressing this key will not have any effect.
Tractors path selected:
- If paper is loaded from the Tractors, pressing this key will park the paper.
- If paper is loaded from the front, pressing this key will have no effect.
- If paper is not loaded, pressing this key will have no effect.
Self-Diagnostics and Failure Indications
At power-on besides a general reset, the printer runs self-diagnostics to check the conditions of critical
components. Upon the successful completion of the self-diagnostics, the printer switches to the online state
with at least L2 and L4 = ON for all emulations.
Failures Beep L1 L2 L3 L4 L5
No power / Power supply failure --- OFF OFF OFF OFF OFF
PE (Paper Error) 1 OFF ON OFF BLINK OFF
Paper jam 1 BLINK BLINK BLINK OFF OFF
Head overheat --- OFF ON OFF BLINK OFF
Hex Dump --- ON ON ON BLINK ON
For other combinations please contact your dealer or Technical Service.
