ally Dascom 5130P
25
Power-On Functions with Cover Open
USER1 OFFLINE USER2 Utilities Remarks
X X
BOOT or Firmware
Upgrade
L1&L2 blink alternatively.
X
Self Test Print Font- and Codepage test page
X
Self Test Endless running ASCII TREE
X Self Test Configuration test page with menu
settings
X*
Suspend cover open
detection
*Press OFFLINE after power on. The
printer resets and goes online.
Firmware Update
With the cover open, hold USER1 and OFFLINE at power-on to activate the Firmware Upgrade process. In
DOS mode, type COPY /B firmware-file LPT1: [Enter] to transfer new firmware to the printer. It takes a few
minutes for completion. Then the printer resets and goes to online.
Power-On Functions with Cover Closed
USER1 OFFLINE USER2 Utilities Remarks
X
Self Test
Print Font- and Codepage test page
X
Self Test
Endless running ASCII TREE
X
Self Test
Configuration test page with menu
settings
X
X
Setup
● Language selection
See Fig 2 for Setup dialogs orientation.
In native languages.
