TASCAM 202MKV 9
Front panel
1STANDBY/ON switch
Thisswitchestheunitpowerbetweenstandbyand
on.
NOTE
The apparatus draws nominal non-operating
power from the AC outlet with its STANDBY/ON
in the Standby position.
2TAPE 1 compartment
3RTZ key (TAPE 1 only)
Thiskeyreturnsthetapetothecounterzeropoint.
4COUNTER RESET keys
Pressingthesekeysresetthetapecounterreadings
forTAPE1andTAPE2,respectively.
5Synchro reverse key (SYNC REVERSE)
Pressingthiskeyactivatesthesynchroreversedub-
bing function.
6REPEAT key
Thisallowsrepeatplaybackofaselectedsectionof
the tape.
7Display
Thisshowstapecounters,levelmeters,etc.
8Parallel record key (PARALLEL REC)
Thiskeyletsyousimultaneouslyrecordonboth
decks.
9Dubbing start key (DUB START)
Thiskeyisusedwhencopyingthecontentsofa
tapefromTAPE1toTAPE2,eitheratnormalor
high speed.
0TAPE 2 compartment
qReverse mode switch (REV MODE)
Thisswitchisusedtoswitchbetweenreverse
modes.
w TIMER switch
Thisswitchisprovidedforusewithacommercially
availableaudiotimer,toallowtimercontrolled
recordingorplayback.
Normally,leavethisswitchtotheOFF position.
eDOLBY NR switch
ThisswitchtogglestheDolbyNoiseReductionsys-
temon/off.Inplaybackyouneedtosetthisswitch
tothesamepositionaswhentherecordingwas
made.
rEJECT ( ) keys
PressingthesekeysopenstheTAPE1andTAPE2
compartments.
tTape transport control keys
RECORD (º) key
Pressingthiskeyshiftsthecorrespondingdeckto
record-pausemode.
PAUSE key
Pressingthiskeytemporarilystopsplaybackor
recording.
Recording mute (REC MUTE) key
Thiskeyisforcreatingthe4-secondblankspace.
