GTS Technical Manual
19. April 2010 Edition: V1.00/2010 6-6
Copyright © 2010, Diversey Inc.
06.0 swingo 1255 B Power - electronics.fm
Pos. Plug Description [plug] Pin Description [pin]
1 X8 Membrane keypad 1 +5V
1 X8 Membrane keypad 2 +5V
1 X8 Membrane keypad 3 Dosing plus (+)
1 X8 Membrane keypad 4 Dosing minus (-)
1 X8 Membrane keypad 5 Dosing ON/OFF
1 X8 Membrane keypad 6 Dosing ON/OFF
1 X8 Membrane keypad 7 LED vacuum motor
1 X8 Membrane keypad 8 LED Dosing level 5
1 X8 Membrane keypad 9 LED Dosing level 4
1 X8 Membrane keypad 10 LED Dosing level 3
1 X8 Membrane keypad 11 LED Dosing level 2
1 X8 Membrane keypad 12 LED Dosing level 1
1 X8 Membrane keypad 13 LED Battery capacity level 4 - green
1 X8 Membrane keypad 14 LED Battery capacity level 3 - green
1 X8 Membrane keypad 15 LED Battery capacity level 2 - green
1 X8 Membrane keypad 16 LED Battery capacity level 1 - green
1 X8 Membrane keypad 17 LED Battery capacity level 1 - red
1 X8 Membrane keypad 18 LED Service
1 X8 Membrane keypad 19 LED charger - charged - green
Table 1: Dashboard connector description
