Taski swingo 1255B User Manual

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 6-7
Copyright © 2010, Diversey Inc.
06.0 swingo 1255 B Power - electronics.fm
1 X8 Membrane keypad 20 LED charger - charge - yellow
1 X8 Membrane keypad 21 LED charger - charge failed - red
1 X8 Membrane keypad 22 GND
2 X1 Communication 1 Throttle signal
2X1Communication 2Serial - OUT
2X1Communication 3Serial - CLK
2X1Communication 4Serial - LATCH
2X1Communication 5Serial - IN
2X1Communication 6Start signal
2X1Communication 7+5V
2X1Communication 8GND
2 X1 Communication 9 (Housing) GND
2 X1 Communication 10 (Housing) GND
3 X7 Throttle hall sensor
(option for old hall sensor ribbon cable)
1 Microswitch (parking = open)
3 X7 Throttle hall sensor
(option for old hall sensor ribbon cable)
2+5V
3 X7 Throttle hall sensor
(option for old hall sensor ribbon cable)
3GND
3 X7 Throttle hall sensor
(option for old hall sensor ribbon cable)
4Throttle (blue wire)
4 X9 Throttle hall sensor 1 Throttle (blue wire)
Pos. Plug Description [plug] Pin Description [pin]
Table 1: Dashboard connector description
