OPERATOR PARTS IDENTIFICATION
4-3
Model 336, 338, 339
Operator Parts Identification
4
Model 339
Figure 4-3
16
3
1
4
5
18
13
14
2
9
10
11
15
20
19
8
7
17
8
12
10
6
6
Item Description Part No.
1 Cover A.-Hopper-Std X38458-SER
2 Gasket-Hopper Cover 038474
3 Orifice 022465-100
4 O-ring 3/8 OD X .070 W 016137
5 Tube A.-Feed SS 5/32 Hole X29429-2
6 O-ring .643 OD X . 077 W 018572
7 Panel-Rear 053782
8 Louver-Side Top 051191
9 Panel-Upper Side Right 028741
10 Panel A.-Lower Side (R/l) X24424-SER
Item Description Part No.
11 Pan-Drip 17-1/4” Long 027504
12 Panel-Upper Side Left 028740
13 Stud-Nose Cone 022822
14 Panel A.-Front X32956
15 Adapter A.-Caster X18915
16 Caster-SWV 5/8 Stem 4” 018794
17 Caster-4” SWV W/Brake 034081
18 Panel-Service 024439
19 Shield-Splash 23 L 022766
20 Tray-Drip 22-7/8l X 5-1/8 W 014533
To Next Page
