Section 5
5-1
Model 336, 338, 339
User Interface
5
User Interface
Figure 5-1
Symbol Definitions
The following chart identifies the symbol definitions used on the operator switches.
4 5
6 6
3 4 5
32
1
7
Item Description
1 Power Switch
2 MIX Button
3STANDBY Button
4 WASH Button
Item Description
5AUTO Button
6 Indicator Light - MIX LOW
7 RESET Button
ON WASH
OFF MIX LOW
MIX STANDBY
