1-2
TO THE INSTALLER
Models 340, 341, 342
To the Installer
1
CAUTION! This machine must be installed on
a level surface to avoid the hazard of tipping. Extreme
care should be taken in moving this machine for any
reason. Two or more persons are required to safely move
this machine. Failure to comply may result in personal
injury or damage to the machine.
The authorized installer should inspect the machine for
damage and promptly report any damage to the local
authorized Taylor distributor.
This machine is made using USA sizes of hardware. All
metric conversions are approximate and vary in size.
Air-Cooled Machine
Do not obstruct air intake and discharge openings:
Model 340 air cooled machine requires a minimum of 6
in. (152 mm) air space on the front, sides and rear.
Model 342 air cooled machine requires a minimum of 3
in. (76 mm) air space around all sides. Install the
deflector to prevent recirculation of warm air.
Failure to allow adequate clearance can reduce the
refrigeration capacity of the freezers and possibly cause
permanent damage to the compressors.
Water Connections
(Water-Cooled Machine Only)
An adequate cold water supply must be provided with a
hand shutoff valve. On the underside rear of the base
pan, two 3/8 in. IPS water connections for inlet and outlet
have been provided for easy hookup. Permanently
connect the machine using ½ in. (12.7 mm) inside
diameter water lines. (Flexible lines are recommended, if
local codes permit.) Depending on local water conditions,
it may be advisable to install a water strainer to prevent
foreign substances from clogging the automatic water
valve. There will be only one water in and one water out
connection. Do not install a hand shutoff valve on the
water out line. Water should always flow in this order:
first, through the automatic water valve; second, through
the condenser; and third, through the outlet fitting to an
open trap drain.
IMPORTANT! A backflow prevention device is
required on the incoming water connection side. Please
see the applicable national, state, and local codes for
determining the proper configuration. Water pressure to
the unit must not exceed 150 psi (1034 kPa).
Electrical Connections
In the United States, this equipment is intended to be
installed in accordance with the National Electrical Code
(NEC), ANSI/NFPA 70-1987. The purpose of the NEC
code is the practical safeguarding of persons and
property from hazards arising from the use of electricity.
This code contains provisions considered necessary for
safety. In all other areas of the world, equipment should
be installed in accordance with the existing local codes.
Please contact your local authorities.
Each machine requires one power supply for each data
label on the machine. Check the data label(s) on the
freezer for branch circuit overcurrent protection or fuse,
circuit ampacity, and other electrical specifications. Refer
to the wiring diagram provided inside of the electrical box
for proper power connections.
WARNING! This machine must be properly
grounded. Failure to do so can result in severe personal
injury from electrical shock.
IMPORTANT! An equipotential grounding lug is
provided with this machine. Some countries require the
grounding lug to be properly attached to the rear of the
frame by the authorized installer. The installation location
is marked by the equipotential bonding symbol (5021 of
IEC 60417-1) on both the removable panel and the
machine's frame.
!
!
FOLLOW YOUR LOCAL ELECTRICAL CODES.
