Page #103 background imageLoading...
Page #103 background image
+ Available Separately
PARTS LIST
5-13
Models C712/C713
Parts List
5
Washer-#6 Sae Flat 18-8 SS 023546 2 2 000
Screw-4-40X1 PHIL. Pan Taptite 045141 2 2 000
Switch-Pressure 440 PSI-Solder 048230 2 2 103
Switch-Reed*Door Interlock*68" 056771 1 1 103
Tool-O-ring Removal-Freezer 048260-WHT 1 1 000
Tool-Mix Pump Shaft Removal 057167 1 000
Trans.-Cont.-32VA 120/200/240V 054834 1 1 103
Trans.-120/208/240V PRI 24VSEC 051660 1 1 103
Tray-Drip-19-5/8 L X 4-7/8 033812 1 1 103
+Shelf-Tray-Drip*712-13*716-1 063877 1 1 103
+Nut-10-32 Nylon Insert Lock 600144 2 2 000
+Screw-10-32X1/2 SLTD Truss 037734 2 2 000
Trim-Corner-Rear-L 059896 1 1 103
Trim-Corner-Rear-R 059897 1 1 103
Tube A.-Feed-Left *C712/C717* X59808 1 103
+O-ring-11/16ODX.103W-Red 016132 4 000
Tube A.-Feed-Right *C712/C717* X59809 1 103
+O-ring-11/16ODX.103W-Red 016132 4 000
Tube A.-Feed-SS-5/32 Hole DIA X29429-2 * 2 103 C712 Feed Tube Optional
+O-ring-.643 OD X .077W 018572 * 8 000
Valve-Access-1/4 MFLX1/4 S-90 047016 1 1 103
Valve-Access 1/4FL X 1/4SOLDER 044404 1 1 103
Valve-Access-1/4MFL X 3/8ODSDR 053565 4 4 103
+Core-Schrader Valve-Teflon 037047 4 4 000
Valve-EPR 1/4S 022665 1 1 103
Description
Part
Number
C712
Qty.
C713
Qty.
Warr. Class Remarks
