CONTROLS
Models C712/C713
Controls
2
Jumper Pin Charts
Jumper Chart - UVC3
** Jumper initially installed at factory.
Table 2-1
** Jumper initially installed at factory.
Table 2-2
** Jumper initially installed at factory.
Table 2-3
Notes:
1. Left and right are determined while facing the front of
machine.
2. Specified feature is established when the jumper is
installed.
3. International mode (jumper removed) enables direct
use of Heat and Standby buttons and hopper
temperature display.
Feature
C712/C713
Left Interface
X59485-SER
C712/C713
Left Interface
X59485-SER
Force Brush Clean Status W2
Syrup Heater Enable W3
Open All Left Solenoids W4
Open All Right Solenoids W4
Clock/Calendar Override W5
Force Glycol Pump On
59F Fault Detection Enable W2**
Standby Stir Cycle Disable W5
Reduced Mix Low Sensitivity W6 W6
Reduced Mix Out Sensitivity W7 W7
7C/45F 90 Min. Cool Phase
Unused W1 W1
Unused W3
Disable Control Panel (Self Serve) J10 - 7 & 8
UVC4 Control Feature Jumper
>41F for 4 hours & >45 for 1 hr JP1 - 1 & 2**
Reserved (do not install) JP1 - 3 & 4
Domestic/International (Note 3) JP2 - 1 & 2 **
Reserved (do not install) JP3 - 3 &4
Audible enable (do not install) JP3 - 1 & 2
Unused JP3 - 3 & 4
Personality Board
0 - 6 Beater Motor Amperage (do not use) A
0 - 12 Beater Motor Amperage B**
