Taylor C712 - User Interface

INTRODUCTION
1-15
Models C712/C713
Introduction
1
User Interface
C712/C713
Figure 1-3
Note: *C713 does not have the Mix Pump Button.
3
2
3
6
4
5
11
7
1
8
9
10
5
6
4
Item Description
1 Power Switch
2 Liquid Crystal Display (LCD)
3 Buttons
4 Mix Out Indicator
5 Standby Button
Item Description
6 Mix Low Indicator
7 Select Button
8 Service Menu Button
9 Brush Clean Counter
10 Arrow Buttons
11 Wash Button
