PARTS LIST

5-15

Models C712/C713

Parts List

Block-Terminal 3P L1,L2,L 039423 1 103 220-240V 50HZ 3PH/200V 50/60HZ 3PH/200V 

50/60HZ 3PH/220-240V 50HZ 1PH

Block-Terminal 2P L1,N 039421 2 2 103 220-240V 50HZ 1PH

Block-Terminal 4P L1,L2,L 039424 2 2 103 380-415V 50HZ 3N~ (4WIRE)/220-380V 60HZ 

3PH-4WIRE

Capacitor A.-RF X58666-1 2 2 103 220-240V 50HZ 1PH

048259-33 2 512 220-240V 50HZ 3PH/200V 50/60HZ 3PH

Compressor L63A113BBKA 048259-40 2 2 512 220-240V 50HZ 1PH

+Capacitor-Run 25UF/370VAC 023739 2 2 103 220-240V 50HZ 1PH

+Capacitor-Start 161-193UF 031790 2 2 103 220-240V 50HZ 1PH

+Relay-Start-Compressor 038146 2 2 103 220-240V 50HZ 1PH

Compressor L63A113DBEA 048259-58 2 2 512 380-415V 50HZ 3N~ (4WIRE)/220-380V 60HZ 

3PH-4WIRE

Diagram-Wiring *C712* 059898-35 1 000 220-240V 50HZ 3PH

Diagram-Wiring *C712* 059898-39 1 000 200V 50/60HZ 3PH

Diagram-Wiring *C712* 059898-40 1 000 220-240V 50HZ 1PH

Diagram-Wiring *C712* 059898-58 1 000 380-415V 50HZ 3N~ (4WIRE)

Diagram-Wiring *C712* 059898-60 1 000 220/380V 60HZ 3PH-4 WIRE

Diagram-Wiring *C713* 059899-35 1 000 220-240V 50HZ 3PH

Diagram-Wiring *C713* 059899-39 1 000 200V 50HZ 3PH/200V 50/60HZ 3PH

Diagram-Wiring *C713* 059899-40 1 000 220-240V 50HZ 1PH

Diagram-Wiring *C713* 059899-58 1 000 380-415V 50HZ 3N~ (4WIRE)

Diagram-Wiring *C713* 059899-60 1 000 220-380V 60HZ 3PH-4 WIRE

Harness-LIQ SOL VLV-GND * 063370-G 2 2 103 200V 50HZ 3PH/220-240V 50HZ 3PH/200V 50/60H 3PH/

220-240V 50HZ 1PH/380-415V 50HZ 

3~(4WIRE)/220-380V 60HZ 3PH-4WIRE

Harness-Wire *C712-C717*C 065436-33 1 103 220-240V 50HZ 3PH/200V 50/60HZ 3PH

Description

Part

Number

C712

Qty.

C713

Qty.

Warr. Class Remarks
