INTRODUCTION
1-17
Models C712/C713
Introduction
1
Beater Motor Overload
The beater motor overloads are located in the rear panel.
The beater motor overload protects the beater motor
from an overload condition. Should an overload occur,
the reset mechanism will trip. To properly reset the
freezer, place the power switch in the OFF position.
Press the reset button firmly. Turn the power switch to
the ON position. Touch the Wash button and observe the
freezer's performance.
DANGER! DO NOT use metal objects to press
the RESET button. Failure to comply may result in severe
personal injury or death.
If the beater motor is turning properly, touch the Wash
button to cancel the cycle. Touch the Auto button
to
resume normal operation. If the freezer shuts down
again, contact your authorized service technician.
Air/Mix Pump Reset Mechanism (C712 Only)
The RESET buttons for the pumps are located in the rear
panel.
The reset protects the pump from overloading. Should an
overload occur, the reset mechanism will trip. To reset
the pump, press the RESET button firmly.
DANGER! DO NOT use metal objects to press
the RESET button. Failure to comply may result in severe
personal injury or death.
Condenser Fan Motor
The condenser fan motor is driven by the software. The
L1 to the fan is connected to the interface board at J6-6.
The condenser fan is programmed to run any time the
compressor is on and to stay running for 30 seconds
after the compressor cycles off.
