2-24
CONTROLS
Models C712/C713
Controls
2
UVC4 Cables - Conversion Kit For Field Replacements
Figure 2-61
The UVC4 board is interchangeable with the UVC3
board. When replacing a UVC3 board in the field, adapter
cables are needed. Cable part number 069024 (1)
connects to the existing USB cable.
Important! See “UVC4 Electrostatic Discharge and
Proper Handling Procedures” on page 2-22 before
handling a UVC4 board.
To Next Page
