Taylor C712 Service Manual

PARTS
4-7
Models C712/C713
Parts
4
C712 Exploded View Parts Identification
*Optional Feed Tube - Can be used instead of mix pump.
Item Description Part No.
1 Kit A.-Cover-Hopper*Dual X67061-SP
2 Pump A.-Mix Simplified X57029-14
3 Panel-Rear 064258-SER
4 Pan-Drip 7.875 059737
5 Panel-Side*Right 059907
6 Pan-Drip 12.5 059736
7 Panel A.-Front-Middle X63879
8 Panel A.-Front-Upper X59836
9 Stud-Nose Cone 055987
10 Filter-Air-Poly-Flo 052779-11
11 Panel A.-Filter-Louvered X59928
12 Caster-4" SWV 3/4-10 STM 044106
13 Screw-1/4-20 X 3/8 RHM 011694
14 Panel-Corner-Front-R 063087
15 Deflector-Blower EXH 047912
Item Description Part No.
16 Caster-4" SWV 3/4-10 Stem w/
Brake
046437
17 Panel A.-Front Lower X59854-SER
18 Shield-Splash-Wire-19-3/4 L 033813
19 Tray-Drip-19-5/8 L X 4-7/8 033812
20 Pan-Drip 19-1/2 Long 035034
21 Panel-Corner-FRNT-L 063088
22 Panel-Side-Left 059906
23 Fastener-Door Latch 030787
24 Fastener-Door Strike 030788
*25 Orifice 022465-100
*26 O-ring-3/8 OD X .070W (100 to
Bag)
016137
*27 O-ring-.643 OD X .077W (50 to
Bag)
018572
*28 Tube A.-Feed-SS-5/32 Hole X29429-2
