4-12
PARTS
Models C712/C713
Parts
4
C713 Exploded View Parts Identification
Item Description Part No.
1 Kit A.-Cover-Hopper X67061-SP
2 Orifice 022465-100
3 O-ring-Pkg (100 to Bag) 016137-SER
4 Tube A.-Feed-SS-5/32 Hole X29429-2
5 O-ring-.643 OD X .077 W 018572
6 Panel-Rear 059917
7 Panel-Side*Right 059907
8 Pan-Drip 12.5 059736
9 Panel A.-Front X63879
10 Panel A.-Front X59836
11 Stud-Nose Cone 055987
12 Filter-Air-Poly-Flo 052779-11
13 Panel A.-Filter-Louvered X59928
Item Description Part No.
14 Caster-4" SWV 3/4-10 STM 044106
15 Screw-1/4-20 X 3/8 RHM 011694
16 Panel-Corner-Frnt-R 063087
17 Caster-4" SWV w/Brake 046437
18 Deflector-Blower 047912
19 Shield-Splash-Wire-19-3/4 L 033813
20 Panel A.-Front Lower X59854-SER
21 Tray-Drip-19-5/8 L X 4-7/8 033812
22 Pan-Drip 19-1/2 Long 035034
23 Panel-Corner-Frnt-L 063088
24 Panel-Side-Left 059906
25 Fastener-Door Latch 030787
26 Fastener-Door Strike 030788
To Next Page
