Taylor C712 Service Manual

4-14
PARTS
Models C712/C713
Parts
4
Control Assembly X67560-27 (C712) Parts Identification
*Not Shown
**Not Included in X67560-27
Item Description Part No.
1 Control-INTERF-HT-SS 063967-SER
1a PCB A.-ROHS-Person-HT-SS 063922-SER
*1b Cntrl-ROHS-INTF-Hotgas 063926-SER
2 Standoff-Nylon-Snap-1/2L 053413
3 Cable-Ribbon-50C-25"L 040040-025
4 Cable-Ribbon-20C-16"L 040040-049
5 Cable-Ribbon-50C-10"L 040040-058
6 Cable-Ribbon-20C-14"L 040040-040
7 PCB A.-Control *UVC4 X69355-SER
7a Control-UVC4 (Base Board) X68114-SER
8 Screw-8x1/4 SLTD Hex 009894
9 Relay-MTR Start TI#4CR 039725-27
10 Trans.-120/208/240V 051660
11 Block-Terminal 1P 073423
12 Capacitor-Start 47-56UF 037251-34
13 Bushing-Snap 1-5/8ID x 2 OD 043637
14 Relay-DPDT 100UA-7A 1/8HP 052111-03
Item Description Part No.
15 Screw-6x5/16 SLTD Round 013646
16 Starter-1 Phase 6.3 to 10A 066794-27K
16a Overload-Thermal-1P 067461-1K
17 Screw-10-32x5/8 UN SL HWH 039382
18 Relay-3 POLE-20A-208/240 066795-33
19 Bushing-Snap 15/16 ID 023396
20 Filter-Corcom 6EH1 040140-001
21 Overload-Thermal-Remot 067965
22 Nut-6-32 KEPS Nut 18-8 SS 054431
23 Screw-6-32x3/8 SLTD Bind 002201
24 Bushing-Snap 11/16 ID x 7/8 010548
25 Trans.-Cont.-32VA 120 054834
26 Cable-Ribbon-20C-17"L 040040-013
*27 Harness-Wire-Cntrl Box 068007
** Holder-Fuse-Inline-HFA 064538
** Fuse-Buss-ABC-15-R ROHS 076414
