Taylor C723 Service Manual

53
Model C723
Parts
150603
Model C723 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X81793-SER
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A.*REDUCER 021286-SER
4 WASHER-5/16 SAE FLAT ZINC 017660-SP
5 SCREW-5/16-18X3-1/4 HEX 022678
6 PULLEY-2AK64-5/8 BORE 039695
7 BELT-AX35 (LEFT) 022848
8 BELT-AX37 (RIGHT) 023447
9 SCREW-5/16-18X5/8 SERR. 017326
10 VALVE-EXP-AUTO-1/4S X 1/4 046365
11 NUT-1/4-20 WHIZ FLANGE LOC 017523
12 MOTOR-1.0 HP 013102-27
13 PULLEY-2AK20 X 5/8 BORE 034238
14 SCREW-1/4-20X5/8 SERRATED 017522
15 SCREW-10-32X1/2 SERRATED 020982
16 LUG-GROUNDING 4-14 GAGE 017667
17 BLOCK-TERMINAL 2P L1,L2 039422
18 SCREW-8X1 1/4 PHLP HD RD 039420
19 FILTER-AIR-18.28X15.5X.70 052779-15
20 CONDENSER A.
(INCLUDES ITEMS 20a-20h)
X81835-SER
20a GUIDE-FILTER-LEFT 081836
20b CONDENSER-AC 16X16 3ROW 056944
20c SHROUD A.-CONDENSER X81838
20d SCREW-10X3/8 SLOTTED HEX 015582
20e SCREW-8X1/4 SLTD HEX 009894
20f MOTOR-FAN 185W 500302-27
20g CAPACITOR-RUN 4.0UF/400V 500311
20h GUIDE-FILTER-RIGHT 081837
21 RING A.-AIR FLOW-COND. X57006
22 SCREW-10-32X3/8 UNSL HWH 039381
23 ACCUMULATOR-COPPER 2" 047062
24 SCREW-10X3/8 SLOTTED HEX 015582
25 COVER-BOX-SPLICE 058122
26 BOX A.-CAP&RELAY X68848-27
SEE PG 60
27 COVER-CAP&RELAY 068850
ITEM DESCRIPTION PART NO.
28 SCREW-8X1/4 SLTD HEX 009894
29 CLAMP-DRYER 9.5" LONG 002911
30 CHANNEL-REAR BEARING 041819
31 PAN A.-DRIP-HINGED X41844
32 SWITCH-TOGGLE-DPDT 054809
33 SWITCH A.-DUAL LEVER X69838
SEE PG 63
34 ACTUATOR A.-DRAW SWITCH X69835
SEE PG 62
35 GUIDE A.-DRIP PAN X51567
36 PLATE A.-DEC X68829-SER
SEE PG 65
37 SCREW-6-32X3/8 SLTD 002201
38 COVER-ACCESS-LEFT 081834
39 PANEL A.-SHELF X81840-SER
39a PANEL A.-FRONT-LOWER X81841
39b SHELF-DRIP TRAY 080782
39c SCREW-1/4-20 X 3/8 SLTD 011694
40 COVER-ACCESS-FRONT-R. 081833
41 VALVE-SOLENOID 7/16 ORF 048626-27
42 COMPRESSOR L64A113BBCA 048259-27E
43 SLEEVE-MOUNTING-COMP. 039924
44 GROMMET-COMPRESSOR MT 037428
45 WASHER-5/16 SAE FLAT ZINC 017660-SP
46 SCREW-5/16-18X1-1/2 HEX 001894
47 SWITCH-PRESSURE 440 PSI 048230
48 VALVE-ACCESS-1/4MFL X 3/8 053565
49 VALVE-SOLENOID 7/64 ORF 043449-27
50 DRYER-FILTER-HP62-3/8 048901
51 CONTROL A.-LOWER X68828-27
SEE PG 59
52 COVER-CONTROL-LOWER 068860
53 MOTOR A.-DANF COND. X68882-27
SEE PG 64
54 CONTROL A.-UPPER X68824-27
SEE PG 58
55 COVER-CONTROL BOX 068856
56 PIN-RETAINING-HOPPER CVR 043934
57 KIT-MOUNTING-COMPRESSOR 047704
58 VALVE-EPR 1/4S 022665
59 COMPRESSOR TL3G-R134A 047701-27
60 STUD-NOSE CONE 055987

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
