101
McDonald's Intelligap Grills
Parts
150720
C832 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PLATEN A.-3100W X73333-23S
2 KIT A.-GREASE SHIELD X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL A.-BACK PNL X72958-SER
3a CAP-PROTECTIVE-PLASTIC 053889
3b HARNESS A.-BACK PNL X74158
3c NUT-LOCKING CONDUIT 1/2" 078327
3d CONNECTOR-MATE LOCK 044823
3e PANEL-BACK TW0 SPEED FAN 072959
4 PANEL A.-BACK SERVICE X72951
5 SCREW-10-32X3/8 SLTD TRUS 024298
6 SCREW-10-32X3/8 UNSL HWH 039381
7 PANEL A.-SIDE UPPER X72965
8 PANEL-SIDE*RIGHT 072968
9 NUT-JAM 1 1/2-12 STEEL 073594
10 CASTER-5" 7-5/8 STEM RIGID 078377
11 CASTER-5" 7-5/8 SWIVEL
W/LOCK
073240
12a-
12g
LON CONTROLS USED S/N M5057035 &
PRIOR
12
CONTROL A.-LON 2 PLATEN
NA (60HZ)
X73231
CONTROL A.-LON 2 PLATEN
EU (50HZ)
X73231-26
ITEM DESCRIPTION PART NO.
12a CONTROL-GATEWAY-LON X72848-SER
12b SCREW-6-32X5/8 041363
12c SCREW-8X1/4 009894
12d FILTER-CORCOM 2VR1 032567
12e SCREW-10X3/8 015582
12f TRANS.-CONT.-40VA 208/240V 053072
12g FILTER-EMI-LINE-250V50/60HZ 073245
13 SCREW-10-32X5/8 UN SL HWH 039382
14 DOOR A.-CONTROL X72485
15 BUTTON-OPERATOR-BLACK 076012
16 BUTTON-OPERATOR-RED 076011
17 PANEL A.-LIGHT X78845
18 CONTROL A.-BOX
(SEE DETAIL ON PAGE 116)
X72514-12
19 COMPRESSOR A.-AIR
(SEE DETAIL ON PAGE 160)
X73128-12
20 PANEL-SIDE*LEFT* 072967
21 PANEL A.-SIDE UPPER*LT X72962
22 CONTROL-DISPLAY X72491-SER
23 SWITCH-ROCKER-DPST-10 076989-WP
To Next Page
