Taylor C845 User Manual

134
Parts
McDonald's Intelligap Grills
Control A.- Switch - X79377-SER / X79377-INT (C832/C834/C835)
Figure 75
ITEM DESCRIPTION PART NO.
1 BUTTON-OPERATOR-RED 076011
2 BUTTON-OPERATOR-BLACK 076012
3 CONNECTOR-MATE LOCK-3 044823
4 BUSHING-SNAP 11/16 ID X 7/8 010548
ITEM DESCRIPTION PART NO.
5 BLOCK-CONTACT 1 NO 076013
* GUARD-LENSE 075288
* LABEL-CONTROL PANEL INTL 075699-SYM
*50 HZ NOT SHOWN
