Taylor C845 User Manual

133
McDonald's Intelligap Grills
Parts
Control A.-Upper - X73696-40 (C845 - 50 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONNECTOR-BX 3/4 STR-2
SCREW
031231
2 HARNESS A.-GAS VALVE X73713-40
3 BLOCK-TERMINAL 2P .25 SPD 073033
4 SCREW-8X1/2 SLTD HEX 075763
5 SOCKET-RELAY-FOR USE
W/05211
052112
6 RELAY-DPDT 100UA TO 7A
1/8HP
052111-03
7 SCREW-6X5/16 SLTD ROUND 013646
8 SCREW-6-32X3/8 SLTD HWH 042022
9 TRANS.-CONT.-80VA 230V/24V 059993
10 SWITCH-PRESSURE 074314
11 SCREW-10-32X1/4 UNSL. HEX. 057361
12 CONTROL-IGNITION 24VAC 079840-03
13 SCREW-6-32X5/8 UNSLTD HWH 041363
14 HOLDER-FUSE-15 A, 250 V 076299
ITEM DESCRIPTION PART NO.
15 HARNESS-SWITCH 073424
16 BLOCK-TERMINAL 4P 1,2,L1,N 051647
17 SCREW-8X1 1/4 PHLP HD RD 039420
18 LUG-GROUNDING 4-14GA WIRE 017667
19 SCREW-1/4-20X5/8 SERRATED 017522
20 RELAY-4P-40A 200/240 COIL 050869-27
21 BLOCK-TERMINAL 1P 073423
22 FILTER A.-*WHT/BLK X78996-40
23 HARNESS-SSR-MIDDLE 073802
24 HARNESS-SSR-RIGHT 073803
25 BUSHING-SNAP 1-3/8ID X 1-3/4 027712
26 HARNESS-SSR-LEFT 073801
27 SCREW-10-32X1/2 SERRATED 020982
28 RELAY-SS 25A NON-ALARM
240 V
074210-02
29 SCREW-10-32X1/2 UNSL HWH 049877
