105
McDonald's Intelligap Grills
Parts
150721
C835 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PLATEN A.-3100W X73333-23
2 KIT A.-GREASE SHIELD X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL A.-BACK PNL X72958-SER
3a CAP-PROTECTIVE-PLASTIC 053889
3b HARNESS A.-BACK PNL X74158
3c NUT-LOCKING CONDUIT 1/2" 078327
3d CONNECTOR-MATE LOCK 044823
4 PANEL A.-BACK SERVICE X73152
5 SCREW-10-32X3/8 SLTD TRUS 024298
6 MANIFOLD A.-GAS-M15E-
3.5WC (SEE PAGE 156)
X79373-02
7 HEATING SYSTEM
(SEE DETAIL ON PAGE 52.)
8 SCREW-10-32X3/8 UNSL HWH 039381
9 PANEL A.-SIDE UPPER X72965
10 PANEL-SIDE*RIGHT* 072968
11 NUT-JAM 1 1/2-12 STEEL 073594
12 CASTER-5" 7-5/8 STEM 078377
13 CASTER-GRILL 5" SWIVEL
W/LOCK
073240
ITEM DESCRIPTION PART NO.
14a-
14g
LON CONTROLS USED M5057035 & PRIOR
14
CONTROL A.-LON 2 PLATEN
NA (60HZ)
X73231
CONTROL A.-LON 2 PLATEN
EU (50HZ)
X73231-26
14a CONTROL-GATEWAY-LON X72848-SER
14b SCREW-6-32X5/8 UNSLTD 041363
14c SCREW-8X1/4 SLTD HEX 009894
14d FILTER-CORCOM 2VR1 032567
14e SCREW-10X3/8 SLOTTED HEX 015582
14f TRANS.-CONT.-40VA 208/240V 053072
14g FILTER-EMI-LINE-LON 073245
15 SCREW-10-32X5/8 UN SL HWH 039382
16 CONTROL A.-BOX
(SEE PAGE 120)
X73133-12
17 DOOR A.-CONTROL X72485
18 PANEL A.-SWITCH X73362
19 COMPRESSOR A.-AIR
(SEE PAGE 162)
X73143-12
20 PANEL-SIDE*LEFT* 072967
21 PANEL A.-SIDE UPPER*LT X72962
22 CONTROL-DISPLAY X72491-SER
23 SWITCH-ROCKER-DPST-10A 076989-WP
24 BUTTON-OPERATOR-RED 076011
25 BUTTON-OPERATOR-BLACK 076012
