Taylor C845 User Manual

107
McDonald's Intelligap Grills
Parts
150720
C836 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PANEL-SIDE *LEFT 074110
2 SCREW-10-32X3/8 SLTD TRUS 024298
3 SCREW-10-32X3/8 UNSL HWH 039381
4 PANEL A.-SIDE UPPER *LT X74126
5 PLATEN A.-3100W SERV X73333-23
6 KIT A.-GREASE SHIELD
(includes items 6a & 6b)
X78330-SER
6a FASTENER-SNAP IN 1/4X15/16 078329
6b SHIELD-GREASE 078285
7 PANEL-BACK TW0 SPEED FAN 072959
8 PANEL-BACK SERVICE 083119
9 PANEL A.-SIDE UPPER *RT X74127
10 PANEL-SIDE *RIGHT 074111
11a-
11f
LON CONTROLS USED S/N M5057035 &
PRIOR
11 CONTROL A.-LON X83096-26
11a CONTROL-GATEWAY-LON X72848-SER
ITEM DESCRIPTION PART NO.
11b FILTER-CORCOM 2VR1 032567
11c SCREW-8X1/4 SLTD HEX 009894
11d FILTER-EMI-LINE-250V50/60HZ 073245
11e SCREW-10X3/8 SLOTTED HEX 015582
11f TRANS.-CONT.-40VA 208/240V 053072
12 SCREW-10-32X5/8 UN SL HWH 039382
13 DOOR A.-LOWER X83094
14 CONTROL A.-BOX X83099-27
15 CONTROL-DISPLAY X72491-SER
16 SWITCH-ROCKER-DPST-10A 076989-WP
17 BUTTON-OPERATOR-BLACK 076012
18 GUARD-LENSE 075288
19 BUTTON-OPERATOR-RED 076011
20 CONTROL A.-SWITCH X74031-INT
21 LABEL-CONTROL PANEL-INTL 075699-SYM
22 COMPRESSOR A. X73288-27
