115
McDonald's Intelligap Grills
Parts
150721
C845 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1
PLATEN A.-2600W 208V SERV
STANDARD 60 HZ
X73182-23
PLATEN A.-2600W 230V SERV
STANDARD 50 HZ
X73182-75
PLATEN A.-2600W SERV
WRAP AROUND 60 HZ
X73598-23
PLATEN A.-2600W 230V SERV
WRAP AROUND 50 HZ
X73598-75
2 KIT A. GREASE-SHIELD X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL A-BACK PANEL
(INCLUDES ITEMS 3A-3E)
X73680
3a PANEL A.-BACK SERVICE X73681
3b CAP-PROTECTIVE PLASTIC 7/8 053889
3c HARNESS A.-BACK PANEL X74158
3d NUT-LOCKING CONDUIT 1/2” 078327
3e CONNECTOR-MATE LOCK-3 044823
4 SCREW-10-32X3/8 SLTD TRUS 024298
5 PANEL-SIDE UPPER-RIGHT 073353
6 PANEL-SIDE-RIGHT 073345-R
7 SCREW-10-32X5/8 UN SL HWH 039381
8 CASTER-5" 7-5/8 STEM 078377
9a-9g LON CONTROLS USED M5057035 & PRIOR
9 CONTROL A.-LON (60HZ) X73483
CONTROL A.-LON (50HZ) X73483-26
9a CONTROL-GATEWAY-LON X72848-SER
9b SCREW-8X1/4 SLTD HEX 009894
9c FILTER-CORCOM 2VR1 032567
9d SCREW-10X3/8 SLOTTED HEX 015582
9e TRANS.-CONT.-40VA 208/240V 053072
ITEM DESCRIPTION PART NO.
9f SCREW-6-32X5/8 UNSLTD 041363
9g FILTER-EMI-LINE-250V
(50HZ ONLY)
073245
10 SCREW-10-32X5/8 UN SL HWH 039382
11
TRANSFORMER A. (60 HZ
(SEE PG 138))
X73649
TRANSFORMER A. (50 HZ)
(SEE PG 138)
X73649-26
12
CONTROL A.-BOX UPPER
(60 HZ) (SEE PG 130)
X73384-12
CONTROL A.-UPPER (50 HZ)
(SEE PG 132)
X73696-40
13
CONTROL A.-LOWER (60HZ)
(SEE PG 127)
X73383-23
CONTROL A.-LOWER (50HZ)
(SEE PG 127)
X73383-75
14 CASTER-GRILL 5" SWIVEL
W/LOCK
073240
15 DOOR A.-CONTROL X73396-12
16
CONTROL A.-SWITCH (60 HZ) X73393
CONTROL A.-SWITCH (50 HZ) X73393-INT
16a GUARD-LENSE
(INTERNATIONAL ONLY)
075288
16b BUTTON-OPERATOR-BLACK 076012
16c BUTTON-OPERATOR-RED 076011
16d PANEL A.-SWITCH X73394
17
COMPRESSOR A.
(SEE PG 165)
X73108-12
18 PANEL-SIDE-LEFT 073345-L
19 PANEL-SIDE UPPER- LEFT 073352
20 SWITCH-ROCKER-DPST-10A 076989-WP
21 CONTROL-DISPLAY X72491-SER
To Next Page
