Taylor C845 User Manual

119
McDonald's Intelligap Grills
Parts
Control A.-Box - X72514-40 (C832 - 50 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONTROL-MOTOR X72436-SER
2 SCREW-6-32X5/8 UNSLTD 041363
3 PANEL-PCB MOUNTING-L 072524
4 SCREW-10-32X3/8 SLTD HEX 044617
5 HARNESS A.-RELAY/PCB 072525
6 RELAY A.-5 HEATER LEFT X74211
7 SCREW-10-32X1/2 SERRATED 020982
8 RELAY-4P-40A 200/240 COIL 050869-27
9 SCREW-8X1/2 SLTD HEX WAS 075763
10 BLOCK-TERMINAL 3P 20A
300V
051331
11 SCREW-8X1/4 SLTD HEX 009894
12 CONNECTOR-BX 1/2 45 DEG 020511
13 BLOCK-TERMINAL 7P GREEN 024156
14 BUSHING-SNAP 15/16 ID 023396
15 NUT-1/4-20 WHIZ FLANGE LOK 017523
16 RELAY A.-5 HEATER RIGHT X74212
ITEM DESCRIPTION PART NO.
17 PANEL-PCB MOUNTING-R 072523
18 FILTER-CORCOM 2VR1 032567
19 BUSHING-SNAP 1-5/8ID X 2 OD 043637
20 BLOCK-TERMINAL 4P 1,2,L1,N 051647
21 SCREW-8X1 1/4 PHLP HD RD 039420
22 HOLDER-FUSE-15 A, 250 V 076299
23 BLOCK-TERMINAL 2P .25 SPD 051644
24 TRANS.-100VA 120/208/240 PRI 079800
25 LUG-GROUND 4-14GA WIRE 017667
26 SCREW-1/4-20X5/8 SERR HW 017522
27 HARNESS-PCB/LOGIC 072527
28 HARNESS-PCB/GR SWITCH 072529
29 FILTER A.-WHT/BLK X78996-40
30 FILTER A.- WHT/BLK X79256
31 LABEL-COPPER COND ONLY 025948
32 LABEL-WIRING CONTROL 079538-40
* HARNESS A.-COMP/TB X79503
*NOT SHOWN
