McDonald's Intelligap Grills
Platen A.-Serv - X73182-23 / -21 (C842/C844/C845) Parts Identification
ITEM DESCRIPTION PART NO.
1 INSULATION-CER FBR 072421
2 THERMOCOUPLE-K TYPE SS 079622
3 SHIELD-HEAT 072422
4 SHIELD-PLATE TUBE INNER 072467-1
5 SCREW-10-32X7/16 LAT HD 065717
6 SHIELD-PLATE SHROUD 072465
7 SHIELD-PLATE SHROUD-
OUTER
072466
8 SHIELD-COUPLING FRONT 072926
9 SHIELD-PLATE TUBE 072467
10 O-RING-1-1/16OD X .103W 052733-118
11 SHIELD-COUPLING REAR 072927
12 O-RING-1-3/16OD X .103W 052733-120
ITEM DESCRIPTION PART NO.
13 GASKET-GORE-TEX .250 DIA 074972-52
14 SCREW-8-32X5/16 SLTD RD 017552
15
CONTROL-LIMIT W/SCREWS
(208V 60 HZ 3 PH)
078721
CONTROL-LIMIT W/SCREWS
(220/380V 60 HZ 3 PH)
074165
16 CABLE-ADJUST-PLATEN 072458
17 SCREW-12-24X1/2 TORX DRIVE 058720
18 WASHER-1/4 EXT TOOTH 000656
19 NUT-10-32 HEX MACHINE
SCREW
038599
20 WASHER-#10 FLAT 18-8 SS 037841
To Next Page
