Taylor C845 User Manual

61
McDonald's Intelligap Grills
Controls and Systems
120807
Approved Gases for Europe - Model C835
Single Categories Double Categories
Gas Category:
I
2E
I
2H
I
2ELL
I
2L
I
3B/P
I
3P
II
2E3B/P
II
2ELL3B/P
II
2H3B/P
II
2L3P
Reference Gas:
G20 G20 G20, G25 G25 G30, G31 G31 G20, G30,
G31
G20, G25,
G30, G31
G20, G30,
G31,
G25, G31
AT‐Austria
Supply Pressure 20 mbar 50 mbar 20/50 mbar
Orifice Size 2.8 mm 2.0 mm 2.8/2.0 mm
Orifice PN 76554‐280 76554‐200 76554‐***
Burner Pressure 7.0 mbar 8.0 mbar 7.0/8.0
mbar
BE‐Belgium,
FR‐France
Supply Pressure
Orifice Size
Orifice PN
Burner Pressure
DE‐Germany
Supply Pressure 20/25 mbar 50 mbar (20/25)/50
mbar
Orifice Size 2.8 mm 2.0 mm (2.8
mm)/2.0
mm
Orifice PN 76554‐280 76554‐200 76554‐***
Burner Pressure 7.0/10.0
mbar
8.0 mbar (7.0/10) /
8.0 mbar
See Note:**
Supply Pressure 20 mbar
Orifice Size 2.8 mm
Orifice PN 76554‐280
Burner Pressure 7.0 mbar
LU‐Luxembourg
Supply Pressure 20 mbar 50 mbar 20/50
mbar
Orifice Size 2.8 mm 2.0 mm 2.8/2.0 mm
Orifice PN 76554‐280 76554‐200 76554‐***
Burner Pressure 7.0 mbar 8.0 mbar 7.0/8.0
mbar
NL‐Netherlands
Supply Pressure 25 mbar 30/50 mbar 25/(30/50)
mbar
Orifice Size 2.8 mm 1.7 mm 2.8/1.7 mm
Orifice PN 76554‐280 76554‐170 76554‐***
Burner Pressure 10.0 mbar 19.8 mbar 10.0/19.8
mbar
Figure 44
* These gas categories appear on the official Gastec Certificate E7305, August 28, 2009
** DK-Denmark, ES-Spain, F1-Finland, GB-Great Britain, GR-Greece, IE-Ireland, IT-Italy, NO-Norway,
PT-Portugal, SE-Sweden, CH-Switzerland
*** The last 3 digits of the Taylor part number correspond to the supply pressure/orifice part number shown in the
single gas category.
