Taymor Concierge 300 - Installation; Cylinder Torque Blade Insertion

INSERT
CYLINDER
TORQUE BLADE
IN HORIZONTAL
POSITION
THE LATCH
BOLT SHOULD
BE IN THE
UNLOCKED
POSITION
THREAD THE CABLE
THROUGH THE HOLE AND
UNDER THE LATCH
® REGISTERED TRADEMARK OF TAYMOR INDUSTRIES LTD. 12
INSTALLATION
FOR INSTALLATION INTO 1-1/2” (38 mm) BORE HOLE:
1. Remove adapter collar by releasing cylinder
mounting screw.
2. Once adapter collar is off, reinstall cylinder
mounting screw.
CYLINDER
MOUNTING
SCREW
ADAPTER COLLAR
