9
SIGNAL FLOW
Jack Cable
Mono to Mono
MIDI Cable
DIN CONNECTOR
5POLE - MALE
180 degrees
DIN CONNECTOR
5POLE - MALE
180 degrees
max. 10m
SHIELDED CABLE (3 or 5 wires + screen)
GND
TIP
TIP
GND
TIP
RING
GND
GND
RING
TIP
Jack Cable
Stereo
