CHAPTER 4 FRONT AND REAR PANEL CONTROLS AND CONNECTORS
4.1 INTROD
UCTION
The Genesys
TM
Power Supply series has a full set of controls, indicators and connectors that allow the
user to easily setup and operate the unit. Before starting to operate the unit, please read the fo
l
lowing
Sections for explanation of the function
s of the controls and connectors terminals.
-
Section 4.2: Front Panel Controls and Indicators.
-
Section 4.3: Rear Panel Connections and Controls.
4.2 FRONT PANEL CONTROLS AND INDICATORS
See Fig.4
-
1 to review the controls, indicators and meters located on
the power supply front panel.
Table 4
-
1: Front Panel controls and indicators
Nu
m
ber
Control/Indicator
Description
Section
1
VOLTAGE control
High resolution rotary encoder for adjusting the Output
Voltage. Also adjusts the OVP/UVL levels and selects the
A
d
dress
5.2.1
5.3.1
5.4.1
7.2.2
2
VOLTAGE indicator
Green LED, lights for constant
-
Voltage mode oper
a
tion.
3
VOLTAGE display
4 digit, 7
-
segment LED display. Normally displays the Ou
t-
put Voltage. When the PREV button is pressed, the display
indicates th
e programmed setting of the Output Voltage.
When the OVP/UVL button is pressed, the Voltage display
ind
i
cates the OVP/UVL setting.
Fig.4-1: Front panel controls and indicators
VOLTAGE
ALARM
FINE
PREV/
OVP
UVL
FOLD
REM/LOC
OUT
DC AMPS
CURRENT
DC VOLTS
POWER
1
14
17
18
19
2
15
16
3
13
10
4
11
5
12
9
6
7
8
