1.2. FEATURE SUMMARY
• Communicate over any standard TCP/IP network
LAN (Local Area Network)
WAN (Wide Area Network)
Communicate across the world using the Internet
• Web page viewable with any web page browser, such as Internet Explorer
Optional password protection prevents unauthorized operation
Program the output settings and protections
Measure the power supply output, view the power supply status
Configure the network connection settings
• LXI Class C
Conforms to LXI standards (revision 1.1) for network configuration
A “LAN Status” indicator shows when the network connection is established
“VXI-11 Discovery” protocol is implemented to search for connected devices
IVI-COM drivers are available for download
Easily write custom automation programs
• Full remote programming functions
Control and read-back of all settings
Full status and error reporting
Uses SCPI command language, an instrumentation standard
Compatible with VISA instrument drivers
(VISA drivers are available for almost any programming language)
Supports network “socket” programming
Same functional features as the IEEE option card.
• Front Panel features
View IP and MAC address on front panel
LAN Reset on front panel
User may remotely “Blink” the front panel to locate a power supply in a rack
• Rear Panel features
RJ-45 connector (standard 8-pin phone jack for LAN)
Link and Activity LED on RJ-45 connector
LAN Status LED shows LAN fault and is a 2
nd
“Blink Identify” on rear panel
A LAN/Serial (RS-232/485) select switch
• RS-485 Multi-drop Chain
Allows connecting up to 30 power supplies
One LAN IP address shared by all RS-485 power supplies
The LAN option is not needed in the RS-485 power supplies, but they must
be Multi-drop enabled
Trademark Notices
LXI is a trademark of the LXI Consortium Inc.
Microsoft and Windows are trademarks of Microsoft Corporation
