5 Printing Operation
!
Attention!
Printhead damage caused by improper handling!
X 'RQRWWRXFKWKHXQGHUVLGHRIWKHSULQWKHDGZLWK¿QJHUVRUVKDUSREMHFWV
X Ensure that the labels are clean.
X Ensure that the label surfaces are smooth. Rough labels act like sandpaper and reduce the service life
of the printhead.
X Print with the lowest possible printhead temperature.
The printer is ready for operation when all connections are established and labels & ribbon are loaded.
5.1 Synchronization of the Paper Feed
$IWHUWKHODEHOPDWHULDOKDVEHHQLQVHUWHGDV\QFKURQL]DWLRQRIWKHSDSHUIHHGLVUHTXLUHG7KH¿UVWGHWHFWHGODEHOZLOO
EHWUDQVSRUWHGWRWKHSULQWSRVLWLRQ$OOODEHOVSULRUWRLWZLOOEHIHGRXWRIWKHSULQWHU7KLVSURFHVVKHOSVDYRLGWKH¿UVW
ODEHOIURPEHLQJWRRORQJZKHQWKHSULQWHULVLQFXWWLQJPRGH7KLVSURFHGXUHPD\UHQGHUWKH¿UVWODEHOXQXVDEOH
X Select to start the synchronization.
X Remove the blank, spent labels after the completion of the synchronization.
i
Note!
Synchronization is not necessary if the printhead was not opened between print jobs, even if the printer was
switched off.
5.2 Tear-off Mode
In tear-off mode, labels or continuous labels are printed. After printing, the label strip can be separated by hand. The
label printer must be equipped with a tear-off plate for this.
