Start level Selection level Parameter/function level
Fig. 8 Menu levels
X To open the menu select
on the start screen.
X Select a topic from the menu.
Several topics have submenus with selection options.
To return from the current level to the previous one select
. To leave the menu select .
X Continue the selection until the parameter/function level is reached.
X Select a function. The printer will carry out the function, possibly after a preparation dialogue.
- or -
Select a parameter to set. The setup possibilities are dependant on the parameter type.
Logical parameters Selection parameters Numerical parameters Date/time
Fig. 9 Examples of setting parameters
Scroll bar for rough value setting
Decreasing the value step-by-step
Increasing the value step-by-step
Return without saving the setting
Return with saving the setting
Parameter is disabled, touching enables the parameter
Parameter is enabled, touching disables the parameter
Table 4 Buttons for setting parameters
3 Touchscreen
