2 Installation
2.4 Connecting the Device
The standard available interfaces and connectors are shown in „Fig. 3 Connectors“.
2.4.1 Connecting the Power Supply
The printer is equipped with a wide area power unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustments.
1. Check that the device is switched off.
2. Plug the power cable into the power connection jack (21). „Fig. 3 Connectors“
3. Plug the power cable into a grounded socket.
2.4.2 Connecting to a Computer or Network
!
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the printer are grounded.
X Connect the printer to a computer or network with a suitable cable.
To connect the printer please consult the Quick start guide (TE document 411-121061) found in the cover of the
Printer CD case.
2.5 Switching on the Device
When all connections have been established:
X Switch the printer on using the power switch (20) in „Fig. 3 Connectors“.
The printer performs a system check, and displays the system status Ready on the screen (9) in „Fig. 1 Overview“.
