TEC tecjet 6090uv-xp600 - Electronic System; Mainboard

TJ UV Printer User Manual
2.10.
Electronic system:
Mainboard:
Flatbed motor /Rotary
Carriage motor signal
Combo function port
Rotary
device
device motor signal cable
cable
motor driver
24V,
42V
power
port
Working
status digit
RX
Receiver
optical
code
cable
from
Carriage
USB
printing
board with TX
cable
Up/Down
TX
Sender
optical
motor signal
cable
from
Carriage
board with RX
Forward
Backward
limit
limit sensor
Up down motor
Rotary/Flatbed
driver
UP/Down signal
signal transit relay
transit board
Combo function port:
11
