TJ UV Printer User Manual
7.2 Calibrate the Y motor gear ratio:
1. Press feed button to move the flatbed to the front and wait it automatic stop:
2. Then we measure the size between the flatbed edge and machine front body cover edge, for example now is86.4cm
86.4cm
86.4cm
3. Then back to the software/Parameters/Y-motor configuration/Move=500/Press Move (Attention: the number can not over
800mm as the TJ max. Y flatbed printing length is 900mm!)
45
