TEC tecjet 6090uv-xp600 - Carriage Board

TJ UV Printer User Manual
Carriage board:
DC42V power port
Encoder sensor port
Home limit sensor
42V+
TX Sender
optical
port
42V+
cable
from
GND
mainboard with RX
GND
Working status digit
code
RX Receiver optical
cable from
mainboard with
TX
White ink Print head
Color ink Print head cable port
cable port
J6 Port connect with Print
head 1 Down cable
J5 Port connect with
Print head 1 UP cable
13
