ELECTRICAL POWER SUPPLY CHECKS
DESCRIPTION POSITIVE NEGATIVE
30
Check the connection of the three phases, neutral and earth.
31
Check that the power supply voltage and frequency are within the
tolerance limits of +/- 10%.
CHECKS FOR AMBIENT SENSOR AND REMOTE TERMINAL CONNECTIONS (IF PRESENT)
DESCRIPTION POSITIVE NEGATIVE
32
Check positioning as described in the installation manual.
33
Check that electrical connection between the sensors and the electrical
panel is as indicated in the wiring diagram and the installation manual.
NOTES ON ANOMALIES ENCOUNTERED DURING CHECKS
…………………………….……………………………………………………………………………………………………………
…………………………….……………………………………………………………………………………………………………
…………………………….……………………………………………………………………………………………………………
…………………………….……………………………………………………………………………………………………………
