Technaxx TX-83 User Manual

4
Technical specifications
Wireless transmission Supports 802.11.b/g/n wireless protocol
Light source 0.5W / 24x high power LED / Ø 650 Lum
Detection Angle 70°~80°, Range 6~10m, PIR 6~8m
Lens F = 3.6mm @ F1.2; Horizonal 60.4°; Mount M12
Shutter 1/50 (1/60) seconds ~ 1/100000 seconds
Time delay control 10 – 120 seconds
Minimum illumination Colour: 1.0 Lux @ F1.2; AGC ON (0 Lux with IR)
B/W: 0.1 Lux @ F1.2; AGC ON (0 Lux with IR)
Video (adjustable) Brightness, Contrast, Sharpness, Saturation
Video stream 128Kbps ~ 4Mbps
Audio compression G.711
Sound detection sensitivity 60dB minimum
Sync Mode Internal synchronous
S/N Ratio > 40dB
Communication interface RJ45 10M/100M self-adaptive Ethernet interface
Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, SMTP, NTP, etc.
Password Password protection
Power supply External power adapter DC 12V (+/- 10%) / 2A
Power consumption 16W maximum
Operating temperature –10°C up to +60°C, humidity 90% or less
Weight / Dimensions 1.2kg / (L) 20 x (W) 15 x (H) 20cm (with Antenna 40cm)
Package Contents
IP-Cam outdoor with LED Floodlight TX-83, 2x screw (A), 1x
screw (D), 2x Plastic plug (B), 1x Crossbar (C), Antenna,
Power adapter, 1x RJ45 cable, Pad for the camera foot,
Waterproof cable protection pack, CD, User Manual
2x screws (A) 1x screw (D) 2x Plastic Plug (B)
1x Crossbar (C)
1x Antenna
1x RJ45 cable
Supports: Windows operating systems; Internet-Browser (Internet Explorer, Mozilla Firefox,
Google Chrome, Opera, Safari); Smartphones (iPhone & Android)

Technaxx TX-83 Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Form factor	-
Mounting type	Wall
Product color	Black
Protection features	Dust resistant
International Protection (IP) code	IP65
Full HD	No
Total megapixels	1 MP
Maximum resolution	1280 x 720 pixels
Supported video modes	720p
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	1280 x 720 (HD 720)
Tilt angle range	70 - 80 °
Camera shutter speed	1/100000 s
Minimum illumination	1 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Ethernet LAN	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP, IP, HTTP, DHCP, DNS, DDNS, SMTP, NTP
Detection distance	10 m
Focus adjustment	1.2
Focal length range	0 - 3.6 mm
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Audio formats supported	G.711
Signal-to-Noise Ratio (SNR)	40 dB
Ethernet LAN (RJ-45) ports	1
DC output current	2 A
DC output voltage	12
Power source type	DC
Power consumption (max)	16 W
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Width	150 mm
Height	200 mm
Weight	1200 g
