Wireless LED
WPS LED
For more information about WPS, see “3.1 Connecting your wireless client via WPS” on page 23.
Ethernet LED
TV LED
Voice LED
Colour State Description
Green Solid on The wireless interface is enabled, no wireless activity.
Blinking The wireless interface is enabled, wireless activity.
Off The wireless interface is disabled.
Both the 2.4 GHz and 5 GHz access point have a dedicated Wireless LED.
Colour State Description
Green Solid On Client successfully registered via WPS.
Orange Blinking WPS registration ongoing.
Red Blinking Error occurred.
Colour State Description
Green Solid on At least one active network device is connected to the Ethernet switch.
Blinking At least one Network device is connected to the Ethernet switch and
sending/receiving data.
Off No active Ethernet devices connected to the Ethernet switch.
Colour State Description
Green Solid on Your Digital TV service is up.
Blinking Your Digital TV service is up and there is activity.
Off Your Digital TV service is down.
Colour State Description
Green Solid on Your VoIP telephony service is up.
Blinking Your VoIP telephony service is up and there is activity.
Off Your VoIP telephony service is down or no VoIP telephony service is
included in your subscription.
