Technics SA-DX950 Operating Instructions

2
RQT5730
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
Please check and identify the supplied
accessories.
AC power supply cord (RJA0065-A)...............................1
Supplied accessories
Table of contents
These operating instructions are applicable to models SA-
DX1050 and SA-DX950, however, are intended primarily for
model SA-DX1050.
AM loop antenna set (RSA0012) .....................................1
(AM loop antenna, antenna holder, screw)
CAUTION
Do not place anything on top of this unit or block the heat
radiation vents in any way. In particular, do not place tape decks
or CD/DVD players on this unit as heat radiated from it can
damage your software.
NO
Refer to the separate booklet, “Remote Control”, for remote
control operation details.
Use the numbers indicated in parentheses when asking for
replacement parts.
(Only for U.S.A.)
To order accessories contact 1-800-332-5368 or web site
(http://www.panasonic.com).
FM indoor antenna (RSA0006) ........................................1
Batteries ............................................................................2
Remote control (EUR7702KA0).......................................1
Before use
Listening caution........................................................................3
PRECAUTIONS
............................................................................4
Control reference guide
...........................................................5
Operations
DSP sound modes...................................................................16
STEREO mode............................................................................16
SURROUND mode......................................................................16
SFC modes..................................................................................17
Enjoying the sounds...............................................................18
Adjusting the tone and balance ...................................................20
Using the VCR 2 terminals ..........................................................20
Using headphones.......................................................................20
Muting the volume .......................................................................21
Adjusting the subwoofer level......................................................21
Using the TAPE MONITOR.........................................................21
Connections
Connections ................................................................................6
Connecting video equipment.........................................................6
Connecting audio equipment.........................................................7
Connecting digital equipment ........................................................7
Antenna connections.....................................................................8
Connecting the AC power supply cord and other information .......9
Speaker connections..............................................................10
Placement of speakers................................................................10
Connecting speakers...................................................................10
Preparations
Customizing your receiver....................................................12
Basic steps ..................................................................................13
Adjusting speaker output level............................................15
Radio functions
The radio.....................................................................................22
Manual tuning..............................................................................22
Preset tuning ...............................................................................23
Reference
Making a recording..................................................................24
The HELP function
...................................................................24
Specifications
...........................................................................25
Maintenance
..............................................................................25
Product Service
........................................................................25
Troubleshooting guide
...........................................................26
Servicenter List (U.S.A.)
.........................................................27
Warranty (U.S.A.)
....................................................Back cover
The model number and serial number of this product can be
found on either the back or the bottom of the unit.
Please note them in the space provided below and keep for
future reference.
MODEL NUMBER
____________________________________
SERIAL NUMBER
____________________________________
DATE OF PURCHASE __________________________
DEALER NAME _______________________________
DEALER ADDRESS ____________________________
_____________________________________________
TELEPHONE NUMBER _________________________
User memo:
