7.2. DC Instrument Power





Figure 14.
7.3. Grounding

-

AccuLoad enclosure and the ground rod.



this is the only ground point.
7.4. Meter Pulses



• Single Channel – 
• Dual Channel – 

channels and post an alarm. Also, this allows the AccuLoad to determine the
direction of flow through the meter.
A4M Module
Factory wired to
AccuLoad internal
modules
To meter transmitters,
remote A4I etc.
Factory wired to
AccuLoad internal
modules
TBE4
+24 VDC
DC GND
9
10
11
12
13
14
15
16
