TechniSat Digit ISIO S2 User Manual

9
The following references (a b c etc.) relate to the illustration on page 18.
4.1 Mains power connection
The digital receiver should only be connected to the mains power supply once you have
finished making all the connections to the various other components. This will prevent
damage to the digital receiver or other components.
a Once you have made all the other connections in accordance with the following
sections, use the power supply unit supplied to connect the receiver to a
230 V/50-60 Hz mains power outlet.
4.2 External unit
4.2.1 Operating with 2 antenna signals
To be able to use the full scope of functions on the digital receiver you should operate the
receiver on two separate antenna signals/antenna cables that are identically set up.
b, c Use appropriate coaxial cables to connect the LNB Inputs 1 and 2 on the digital
receiver to your external unit.
Note Section 7.6 (Antenna Settings) as well.
4.2.2 Operating with 1 antenna signal
In exceptional cases you can also operate the receiver using just one antenna signal.
However, in this event the recording and PiP functions are only available to a limited extent.
(see section 7.6.3)
b Connect the LNB input 1 on the digital receiver to your external unit using a suitable
coaxial cable.
4.2.3 Operating with a rotating system
b During operation on a rotating system, connect the DiSEqC motor (level 1.2) with LNB
input 1.
4.3 Connecting to a TV
d Connect the receiver (HDMI output) and TV receiver (HDMI input) using an HDMI
cable.
If your TV set is equipped appropriately, it will automatically switch to the HDMI input
when the digital receiver is switched on.
Alternatively:
Connect the receiver (mini TV SCART socket) and the TV (SCART socket) via
a mini SCART adapter (e.g. part no. 0000/3602) and a SCART cable.
If your TV is equipped appropriately, it will automatically switch to AV - and hence
satellite mode - when the digital receiver is switched on. It may be necessary to adjust
the signal type on your TV (see section 7.3.6).

TechniSat Digit ISIO S2 Specifications

General

Signal source	Satellite
Digital signal format system	DVB-S, DVB-S2
Personal Video Recorder (PVR) included	-
Tuner type	Digital
Product color	Silver
Number of tuners	2 tuner(s)
Channels quantity	10000 channels
Audio output channels	- channels
Favorite list TV programs	10000
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2, Sat-CR
Audio formats supported	FLAC, M4A, MP2, MP3, OGG, WAV
Image formats supported	BMP, GIF, JPG, PNG, TIF
Video formats supported	ASF, AVI, H.264, MKV, MOV, MP4, MPEG1, MPEG2, MPEG4, MPG, TS, TS4, VOB, WMV
Built-in HDD	No
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	13 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Display type	VFD
