3.7- Running a G-code File
Once the XY and Z zero positions have be set, the machine is now ready to execute a G-code
program.
Make sure your material is properly secured, the correct bit is inside the spindle and that the
operatorhasthepropersafetyequipmenton.
Warning: Itisadvisedforrsttimeuserstoruntheleintheairtobecomemore
familiar with operations.
Loading a G-code File
ToloadaG-codeletobecut,select“File”fromtheMenubarandthenchoose“Open”.
Thenusingtheexplorerwindow,navigatetotheG-codeleyouwouldliketorunandchoose
“Open”.
OncetheG-codelehasbeenselectedandloaded,thenetworklocationofthelewillbeshownin
the command window.
After loading a File
Oncetheleisloaded,theoperatorcanView,Simulate,andthenrunthele.
View
(File>View) or
ThisoptiondisplaysthetoolpathsoftheG-codeleintheviewerwindowofthecontrollerscreen.
It allows the user to see exactly what is being cut on a simulated view of the machine bed.
Simulate
(File>Simulate) or
Thisoptionsimulatesaletocheckforerrorsandestimatesruntime.
Run
(Enter key) or
ThisoptiondisplaysthetoolpathsoftheG-codeleintheviewerwindowofthecontrollerscreen.
It allows the user to see exactly what is being cut on a simulated view of the machine bed.
