Titan Series WinCNC Manual
WinCNC
I. Initial Setup
Remove the controller and place it on the oor to the left of the machine.
When unpacking the controller, avoid twisting the cable carrier that guides the cables to the motors.
Carefully remove the Titan from its wood pallet. Be sure to remove the bolts from its four leveling feet
insertion holes, as well as anything stowed under the Titan during shipping.
Remove all bubble wrap, foam and strapping from the machine.
Attached the provided leveling feet to the six legs and adjust accordingly until the table is level.
Remove the four brackets used to stabilize
the gantry during shipping using metric allen
wrenchs.
1.1 Techno Titan Series Installation
