7.7. DISASSEMBLING THE UPRIGHT GUARD
Figure 7.7-1
1. Turn off the machine and unplug the mains
lead from the wall output.
2. Unscrew the 6 screws a which secure the
UPRIGHT GUARD, using a large Phillips
screwdriver.
3. Remove the UPRIGHT GUARD.
To reassemble the UPRIGHT GUARD, carry out
the above steps in reverse order.
